Main Technical Data

Model

FB10

(CPD10)

FB15

(CPD15)

FB20

(CPD20)

FB25

(CPD25)

FB30

(CPD30)

FB35

(CPD35)

Power Type

Battery

Battery

48V/450Ah

48V/450Ah

48V/500Ah

48V/620Ah

80V/500Ah

80V/500Ah

Controller  Type

AC

Controller Manufacturer

 ZAPI/CURTIS

Rated load Capacity(kg)

1000

1500

2000

2500

3000

3500

Lifting Height(mm)

3000

Load Centre(mm)

500

Overall Dimensions(mm)

2150x1090x2125

2150x1090x2125

2380x1150x2125

2380x1150x2125

2475x1225x2125

2535x1225x2125

Turning Radius(mm)

1995

1995

2080

2080

2215

2280

Tires

Front:6.50-10-10PR/Rear:5.00-8-8PR(Pneumatic)

Front:6.50-10-10PR/Rear:5.00-8-8PR(Pneumatic)

Front:7.00-12-12PR/Rear: 18×7-8-14PR(Pneumatic)

 Front:7.00-12-12PR/Rear: 18×7-8-14PR(Pneumatic)

Front:28×9-15 /Rear:18×7-8(Pneumatic)

 Front:28×9-15 /Rear:18×7-8(Pneumatic)

Self Weight(kg)

2890

3060

4160

4420

5160

Characteristics & Advantages

Zero-Emission,Zero-Pollution,Low-Level Vibration,Low-Level Vibration,Low Operation Cost, High Efficiency ,High Quality,these are the reasons for you to choose a VSM Electric Forklift.

The most advanced 3-phase full AC technology in VSM’s electric range combining the Italian ZAPI electric controller,ZAPI-SUPEREC AC motors,and HAKWER battery,as well as the excellent hydraulic system,these features guarantee your material handling become the most cost-efficient.

The Energy Regeneration Function extend extra 15% working hours,which provides the possibility for your tough and long-time working condition.

Features & Functions

Full AC System
OPS System
Comfortable Operator Space
Fast Battery Charge and Long Battery Working Time
Lower Energy Consumption and Energy Regeneration Function
Easy-to-read operator display
Low Gravity

Joystick (Option)
